VisualCAD/CAM Application at Lane Manufacturing

This document is a case study detailing the application of VisualCAD/CAM at Lane Manufacturing. It outlines the company's history and operations, including their establishment in Lebanon, Oregon, and their expansion with a full CNC mold shop and additional warehouse space. The case study presents remarks from Casey Simmons, a Lead Machinist, regarding the cost-performance balance of VisualCAM as the primary CAM application utilized for machining. The document describes the machining processes involved in creating a set of cavity inserts for a 3-plate mold used in injection molding quad-ring seals. It discusses the specific cutting tools used, including a 2-flute CARBIDE ball undercutting end mill, and the detailed multi-step machining operations required to achieve the desired precision for the quad-ring seal cavities. The document concludes with visuals of the completed machining job and the prototype seal produced, showcasing the capabilities of VisualCAD/CAM software.
